Setaclean Total Sediment Tester – 16120-2
The Setaclean Total Sediment Tester is a compact bench-mounted unit for determining the insoluble material content of distillate and residual fuel oils.
Methods
ASTM D4870, IP 375, IP 390, BS ISO 10307-1, BS ISO 10307-2 & BS 2000-390
Features
- Measures sediment up to 0.5% m/m
- Sample viscosities up to 55 mm²/s at 100 °C
- 10 g sample size
- Two test stations
Details
Consists of two filtration cells, heating (steam) and cooling (water) circuits, and a vacuum circuit with Buchner flask and gauge.
Each filtration cell comprises a steam heated/water cooled brass cup with a sintered brass disk to support the microfibre filters.
Temperature test points are fitted into the steam input lines, and a digital indicator and probe are available as an accessory.
Supplied with;
Buchner flask with safety cover
2 x filtration cells
100 x filters
Instruction manual
Specifications
| Test samples | 10 g |
| Waste flask capacity | 500 ml |
| Filters | 2 per cell 47 mm dia Whatman Type GF/A |
| Services | Steam 100 °C Vacuum 40 kPa absolute pressure Cooling water – ambient temperature |
| Connections | 10 mm diameter riffled nozzles |
| Size (HxWxD) | 40x47x18 cm |
| Weight | 8 kg |
