SetaCool-20 – 94165-0
The SetaCool-20 is designed to provide fast, accurate and precise determination of Cloud Point, Pour Point and Cold Filter Plugging Point of petroleum products, diesel and cooling fuels to -78 °C.
Five independent units, each with four test jackets allows for easier maintenance and servicing. The instrument features a built in cooling system and dry block bath which means no external cooling medium is required, whilst a built in heated top plate prevents ice formation.
A state of the art cooling system eliminates the use of compressors and HFC (greenhouse gas) or flammable refrigerants, providing a safe and environmentally sustainable solution.
Methods
ASTM D97, ASTM D2500, ASTM D5853, ASTM D6371, IP 15, IP 219, IP 309, IP 441, BS 2000-15 & ISO 3016, BS EN 116 & BS 2000-309, BS EN 23015 & BS 2000-219 & ISO 3015
Features
- Ambient to -78 °C
- Temperature stability +/- 0.2 °C or better
- Built in cooling
- 5 independent unit x 4 test jackets
- Low power consumption
Details
The SetaCool-20 is operated via a simple to use digital controller and consists of a dry block bath with five units x four test jackets. The temperature is set and sample is cooled as specified by the test method. A thermometer well is used to verify the bath temperature is correct. Test results are observed as specified by the test method.
For safety, the SetaCool-20 consists of a heated top plate to prevent condensation and ice forming when the bath is cooling.
Specifications
| Number of test jackets | 4 places x 5 units |
| Cooling temperature range | Adjustable beween Ambient to -78°C with PID control |
| Temperature stability | +/- 0.2°C or better |
| Temperature display resolution | 1 decimal place |
| Power | 100 V to 240 Vac 50/60 Hz |
| Size (HxWxD) | Individual unit: 45 x 32 x 24.9 cm |
| Weight | Individual unit 19.4 kg |
