Setaflash Series 3 Flash Point Tester – 30000-3
Regulations EC No 1272/2008EPA 1020 BISO 3679ISO 3680 (Obs)SW-846 1020C
The Setaflash Series 3 closed cup flash point tester provides fast and reliable flash point results and requires minimum expertise.
With the Series 3, a test takes less than 2 minutes with just a 2 or 4 ml sample size. A simple user interface with colour digital display and touchscreen icons guides you through the straightforward testing process. For easy record keeping the instrument stores 100,000 test results which can be saved and transferred via a USB port.
Designed for precise and accurate tests, barometric pressure is measured by an internal barometer and correction is automatically applied to the test result. Unknown samples can be tested using ramp mode.
Methods
ASTM D1655, ASTM D3278, ASTM D3828, ASTM D7236, ASTM D8174, ASTM E502, IP 523, IP 524, IP 534, CLP Regulations EC No 1272/2008, EPA 1020 B, ISO 3679, ISO 3680 (Obs)
Features
- Ambient to 300 °C
- Simple test procedure
- Compact, rugged design
- Automated flash detection
- Ramp mode
- Automatic barometric pressure correction
- USB port and result storage
Details
Ease of use:
All functions on the Series 3 including test parameters, instrument status and test results are accessed via the touchscreen display and push button. An audible prompt sounds when a flash is achieved and an automatic flash detector enhances repeatability.
Calibration and verification:
Calibration of the Series 3 can be performed in the field, eliminating the costs and time associated with sending the instrument to a service centre.
Service and maintenance:
The rugged design ensures minimal operational maintenance in needed.
Supplied with: 2 ml syringe, ignitor, Allen key, mains lead, quick start guide and instruction manual
Specifications
| Temperature range | 10 to 135 °C |
| Temperature selection | °C or °F |
| Heating/cooling method | Cartridge |
| Temperature ramp mode | Up to 6 °C/min |
| Data storage | 1 G |
| Voltage | 100 to 240 Vac, 50/60 Hz |
| Size/Weight | 19.5 cm x 29.5 cm x 14 cm / 3 kg |
