Tost Dry Block Bath – 6 Way with Oxflo – 16645-2
The Seta TOST Bath is a compact solid block bath which can accept up to 6 sets of oxidation glassware and is suitable for TOST tests and as an alternative to liquid filled baths.
Methods
ASTM D943, IP 157(*Alternative to ASTM D2274-IP 388), ISO 4263, ISO 12205
Features
- 6 positions
- Dry block bath
- Ambient to 100 °C temperature range
- Integral Setatemp controller
- Seta Oxflo Controller and flowmeters included
Details
The solid block bath can accept up to 6 sets of oxidation glassware. The layout of the heating elements give an even temperature distribution and the integral Setatemp 50K Temperature Controller ensures stability over extended test times. Safety features include over-temperature cut-out.
The Seta Oxflo Controller (supplied) comprises an inlet pressure regulator, pressure gauge and six precision flowmeters with tubes and floats calibrated for oxygen at 3 litres/hour, 21 °C and 0.4 bar pressure.
Supplied with;
6 place Seta Oxflo Controller with gas inlet pressure regulation
Pressure gauge and six precision flowmeters calibrated at 3 litres/hr
Specifications
| Temperature range | Ambient to 100 °C |
| Temperature control at 95 °C | Uniformity: ±0.1 °C Stability ±0.03 °C |
| Bath type | Solid Block |
| Power | 2 kW |
| Voltage | 220/240 V, 50/60 Hz For 110 V contact Seta |
| Size (HxWxD) | Bath: 50 x 25 x 64 cm, Oxflo Control Unit: 44 x 35 x 26 cm |
| Weight | Bath: 80 kg, Oxflo Control Unit: 11 kg |
